Thursday, September 20, 2018

Image Kernels

Find interesting link on CNN

Reference link:

Keras Inception V3 weights loading error

Got below error while loading the weights

After i spent lot of time on google, i thought this is our network issue. I restarted my notebook and attempted. That's it.

Wednesday, September 19, 2018

Elevated permissions in SharePoint Designer 2013

In SPD 2010 we have option called "Replace permissions".
In SPD 2013 we have option with "App step". For this needs to do few configuration steps.

Reference Link:

Tuesday, September 18, 2018

Image segmentation with Intersection Over Union (IOU)

If we plot the data it looks like the below

Encoder and Decoder is the common Convolution model for Image segmentation
How Do We Evaluate Semantic Segmentation Models?
  • Intersection Over Union (IOU)
  • IOU is a robust measure of segmentation accuracy

Plot predictions vs truth
num_samples = 20
fig = plt.figure(figsize=(10, 2*num_samples))

for i in range(0, 4*num_samples, 4):
    segment_pred = model.predict(np.array([X_test[i,...]]))
    ax = fig.add_subplot(num_samples, 4, i+1, xticks=[], yticks=[])
    segment_truth = y_test[i,:].reshape(im_size, im_size, 2)[:,:,1]
    ax.imshow(X_test[i,:].reshape(im_size, im_size, 3), interpolation='nearest')
    ax = fig.add_subplot(num_samples, 4, i+2, xticks=[], yticks=[])
    ax.imshow(segment_truth, interpolation='nearest')
    ax = fig.add_subplot(num_samples, 4, i+3, xticks=[], yticks=[])
    ax.imshow(segment_pred.reshape(im_size, im_size, 2)[:,:,1], interpolation='nearest')
    ax = fig.add_subplot(num_samples, 4, i+4, xticks=[], yticks=[])
    binary_pred = segment_pred.reshape(im_size, im_size, 2)[:,:,1] > 0.5
    ax.imshow(binary_pred, interpolation='nearest')

    binary_pred_flat = binary_pred.reshape(im_size* im_size)
    segment_truth_flat = segment_truth.reshape(im_size* im_size)
    intersection = np.sum((binary_pred_flat + segment_truth_flat == 2.0))
    union = np.sum(np.clip((binary_pred_flat + segment_truth_flat), 0.0, 1.0))

    iou = intersection/union
    ax.set_title('IOU = {}'.format(iou))

1st column- Original flower
2nd column --Target/Ground truth
3rd column represents Our network predicted
4th column Threshold prediction with IOU

Reference link:

Monday, September 17, 2018

Keras: Error while training the model

While running a Keras model have encountered an error like the below
Keras expects y-data in (N, 17) shape, not (N,) as have probably provided, that's why it raises an error.
class_index_one_hot = keras.utils.to_categorical(class_index, 17)
Output Ex: class_index_one_hot: [0. 0. 0. 0. 0. 0. 0. 0. 0. 0. 0. 0. 0. 0. 0. 0. 1.]
y_train shape: (911, 17)
y_test shape: (449, 17)

Friday, September 14, 2018

Image Classification with Convolutional Neural Networks, CIFAR-10 dataset

Dataset can be found here:
The dataset is broken into batches to prevent your machine from running out of memory. The CIFAR-10 dataset consists of 5 batches, named data_batch_1, data_batch_2, etc.. Each batch contains the labels and images that are one of the following:
  • 0 - airplane
  • 1 - automobile
  • 2 - bird
  • 3 - cat
  • 4 - deer
  • 5 - dog
  • 6 - frog
  • 7 - horse
  • 8 - ship
  • 9 - truck
import tarfile
with"D:\\NAVEED\\cifar-10\\cifar-10-python.tar.gz") as tar:

Load and pre-process files

  • Access the image and the labels from a single batch specified by id (1-5)
  • Reshape the images, the images are fed to the convolutional layer as a 4-D tensor, notice that the reshape has the channels at axis index 1
  • Transpose the axes of the reshaped image to be in this form: [batch_size, height, width, channels]channels should be the last axis
import pickle
CIFAR10_DATASET_FOLDER = "cifar-10-batches-py"

def load_cifar10_batch(batch_id):
    #with open(CIFAR10_DATASET_FOLDER + '/data_batch_' + str(batch_id), mode='rb') as file:
    with open("D:\\NAVEED\\cifar-10\\cifar-10-python\\cifar-10-batches-py\\data_batch_1", mode='rb') as file:
        batch = pickle.load(file, encoding='latin1')

    features = batch['data'].reshape((len(batch['data']), 3, 32, 32)).transpose(0, 2, 3, 1)

 labels = batch['labels']

    return features, labels

features, labels = load_cifar10_batch(1)
(10000, 32, 32, 3)

Access the training& test data and the corresponding labels

Each batch in the CIFAR-10 dataset has randomly picked images, so the images come pre-shuffled
train_size = int(len(features)*0.8)
training_images = features[:train_size,:,:]
training_labels = features[:train_size]
print("Training Images:",len(training_images))
print("Training Labels:",len(training_labels))
Training Images: 8000
Training Labels: 8000
test_images = features[train_size:,:,:]
test_labels = labels[train_size:]

print("Test images: ", len(test_images))
print("Test labels: ", len(test_labels))
Test images:  2000
Test labels:  2000
height = 32
width = 32
channels = 3
n_inputs = height * width

Placeholders for training data and labels

  • The training dataset placeholder can have any number of instances and each instance is an array of 32x32 pixels (we've already reshaped the data earlier)
  • The images are fed to the convolutional layer as a 4D tensor [batch_size, height, width, channels]
X = tf.placeholder(tf.float32, shape=[None, height, width, channels], name="X")

Add a dropout layer to avoid overfitting the training data

  • The training flag is set to False during prediction and is True while training (dropout is applied only in the training phase)
  • The dropout_rate indicates the chances that a neuron is turned off during training
dropout_rate = 0.3 training = tf.placeholder_with_default(False,shape=(),name='training') X_drop = tf.layers.dropout(X,dropout_rate,training=training)
y = tf.placeholder(tf.int32,shape=[None],name="y")

Neural network design

  • 2 convolutional layers
  • 1 max pooling layer
  • 1 convolutional layer
  • 1 max pooling layer
  • 2 fully connected layers
  • Output logits layer
  • Specify the number of feature maps in each layer, a feature map highlights that area in an image which is most similar to the filter applied
  • The kernel size indicates the dimensions of the filter which is applied to the image. The filter variables are created for you and initialized randomly
  • The stride is the steps by which the filter moves over the input, the distance between two receptive fields on the input
  • "SAME" padding indicates that the convolutional layer uses zero padding on the inputs and will consider all inputs
conv1 = tf.layers.conv2d(X_drop, filters=32,
                         kernel_size=3,strides=1, padding="SAME", activation=tf.nn.relu, name="conv1")
conv2 = tf.layers.conv2d(conv1, filters=64,
                         kernel_size=3,   strides=2, padding="SAME",  activation=tf.nn.relu, name="conv2")
TensorShape([Dimension(None), Dimension(32), Dimension(32), Dimension(32)])
TensorShape([Dimension(None), Dimension(16), Dimension(16), Dimension(64)])

Connect a max pooling layer

  • The filter is a 2x2 filter
  • The stride is 2 both horizontally and vertically
  • This results in an image that is 1/4th the size of the original image

pool3 = tf.nn.max_pool(conv2,ksize=[1, 2, 2, 1],strides=[1, 2, 2, 1], padding="VALID") pool3.shape TensorShape([Dimension(None), Dimension(8), Dimension(8), Dimension(64)]) conv4 = tf.layers.conv2d(pool3, filters=128, kernel_size=4, strides=3, padding="SAME", activation=tf.nn.relu, name="conv4") conv4.shape TensorShape([Dimension(None), Dimension(3), Dimension(3), Dimension(128)])

Reshape the pooled layer to be a 1-D vector (flatten it)

pool5 = tf.nn.max_pool(conv4, ksize=[1, 2, 2, 1], strides=[1, 1, 1, 1],padding="VALID") pool5.shape TensorShape([Dimension(None), Dimension(2), Dimension(2), Dimension(128)]) pool5_flat = tf.reshape(pool5, shape=[-1, 128 * 2 * 2]) fullyconn1 = tf.layers.dense(pool5_flat, 128, activation=tf.nn.relu, name="fc1") fullyconn2 = tf.layers.dense(fullyconn1, 64, activation=tf.nn.relu, name="fc2")

The final output layer with softmax activation

Do not apply the softmax activation to this layer. The tf.nn.sparse_softmax_cross_entropy_with_logits will apply the softmax activation as well as calculate the cross-entropy as our cost function
logits = tf.layers.dense(fullyconn2, 10, name="output")
xentropy = tf.nn.sparse_softmax_cross_entropy_with_logits(logits=logits, labels=y)
loss = tf.reduce_mean(xentropy)
optimizer = tf.train.AdamOptimizer()
training_op = optimizer.minimize(loss)

Check correctness and accuracy of the prediction

  • Check whether the highest probability output in logits is equal to the y-label
  • Check the accuracy across all predictions (How many predictions did we get right?)
correct = tf.nn.in_top_k(logits, y, 1) accuracy = tf.reduce_mean(tf.cast(correct, tf.float32))

init = tf.global_variables_initializer()
saver = tf.train.Saver()

Set up a helper method to access training data in batches

def get_next_batch(features, labels, train_size, batch_index, batch_size): training_images = features[:train_size,:,:] training_labels = labels[:train_size] test_images = features[train_size:,:,:] test_labels = labels[train_size:] start_index = batch_index * batch_size end_index = start_index + batch_size return features[start_index:end_index,:,:], labels[start_index:end_index], test_images, test_labels

Train and evaluate the model

  • For smaller training data you'll find that the model performs poorly, it improves as you increase the size of the training data (use all batches)
  • Ensure that dropout is enabled during training to avoid overfitting
n_epochs = 10 batch_size = 128 with tf.Session() as sess: for epoch in range(n_epochs): # Add this in when we want to run the training on all batches in CIFAR-10 for batch_id in range(1, 6): batch_index = 0 features, labels = load_cifar10_batch(batch_id) train_size = int(len(features) * 0.8) for iteration in range(train_size // batch_size): X_batch, y_batch, test_images, test_labels = get_next_batch(features, labels, train_size, batch_index, batch_size) batch_index += 1, feed_dict={X: X_batch, y: y_batch, training: True}) acc_train = accuracy.eval(feed_dict={X: X_batch, y: y_batch}) acc_test = accuracy.eval(feed_dict={X: test_images, y: test_labels}) print(epoch, "Train accuracy:", acc_train, "Test accuracy:", acc_test) save_path =, "./my_mnist_model")
9 Train accuracy: 0.73125 Test accuracy: 0.7135
Reference links:

Monday, September 3, 2018

Everybody Dance Now! - AI-Based Motion Transfer

Amazing work on Motion transfer.
Additional Key Words and Phrases: Motion transfer, Video generation, Generative adversarial networks
